24V car A/C compressor evaporator kit, applicable to cars, vintage cars, RV, trucks, agricultural vehicles, vans, etc., DC air conditioning system (24V voltage)

1

• This air conditioner kit is suitable for retrofitting car air conditioners. The air-conditioning system is driven by batteries, which will greatly reduce gasoline costs, realize low noise, environmental protection, energy saving and economy. Compared to traditional mechanical air conditioning kits, electric air conditioning kits can save a considerable amount of fuel bills each year.
• Electric compressor parameters: Voltage: 24V DC。starting current: 45-60A。 rated speed: 3000 rpm。 refrigeration oil: POE / 130ml - 150ml (Oil has already in compressor )。cooling capacity: 10000BTU。 rated power: 850W。 displacement: 21cm³/r
• Evaporator parameters: Voltage: 24V . Cooling Type: Cooling only. Coils: 32-Way 4-Way Aluminum and Copper Coils. Motor power: 80 watts. Motor speed: 3800rpm. Switch: three positions air switch and temperature switch. Expansion valve: 1.5 Ton O-ring expansion valve
• DC Controller Panel: 24V DC Overvoltage Protection: 42V. 24V DC under-voltage protection: 20.5V. Maximum power: 600W
• If you don't have an air conditioner in your car, using this air conditioner is a very good choice. Applicable to: cars, pickups, RVs, trucks, vans, buses, excavators, construction vehicles, classic cars, etc.
• Matters needing attention: 1. Please check whether the battery is 24V and whether the current reaches 45-60A before purchasing. 2. Add R134a/600g. 3. The air conditioner is powered by battery and will not affect the original horsepower of the car. 4. The compressor must be installed upright (feet down), and the evaporator needs to be installed horizontally or the air outlet is slightly upward. If the evaporator is installed at other angles, it is not conducive to drainage. Other parts can be installed at any angle. 5. If you have any questions that you do not understand, please feel free to contact us.
